AMD Ryzen™ 7 5700G
General Specifications
Platform
Boxed Processor
Product Family
AMD Ryzen™ Processors
Product Line
AMD Ryzen™ 7 5000 G-Series Desktop Processors with Radeon™ Graphics
# of CPU Cores
8
# of Threads
16
Max. Boost Clock
Up to 4.6GHz
Base Clock
3.8GHz
L2 Cache
4MB
L3 Cache
16MB
Default TDP
65W
AMD Configurable TDP (cTDP)
45-65W
Processor Technology for CPU Cores
TSMC 7nm FinFET
Unlocked for Overclocking
Yes
CPU Socket
AM4
Thermal Solution (PIB)
Wraith Stealth
Max. Operating Temperature (Tjmax)
95°C
Launch Date
4/13/2021
*OS Support
Windows 10 – 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer.
Connectivity
PCI Express® Version
PCIe® 3.0
System Memory Type
DDR4
Memory Channels
2
System Memory Specification
Up to 3200MT/s
Graphics Capabilities
Graphics Model
Radeon™ Graphics
Graphics Core Count
8
Graphics Frequency
2000 MHz
Product IDs
Product ID Boxed
100-100000263BOX
Product ID Tray
100-000000263
Product ID MPK
100-100000263MPK
AMD Ryzen 7 5700G (až 4,6GHz / 20MB / 65W / SocAM4) Box, Chladic
Model:
Modelové označení: Athlon II X2
Patice: Socket AM3
Jádro: Regor
Frekvence:
Pracovní frekvence [MHz]: 2900
Cache:
Velikost L1 cache [kB]: 256
Velikost L2 cache [kB]: 2048
Ostatní parametry:
Pracovní napětí [V]: 1,425
Techno
14 na sklade
Ďalšie informácie
| Hmotnosť | 0,44000 kg |
|---|---|
| Rozmery | 13,3 × 7,6 × 14,1 cm |
| Kategória | |
| Určenie | |
| Výrobca procesora | |
| Rad procesora | |
| Socket (pätice) | |
| Počet jadier | |
| Integrovaná grafika | |
| HyperTrading | |
| Možnosť pretaktovania | |
| Chladič v balení |
