Refresh Your Style
Q300L V2
High Flexibility for System Building
Minimized Dimension with ATX PSU Support
Redesigned Patterned Dust Filter
Clean Routing Space
Excellent Thermal Performance
Edge-to-Edge Temper-Glass Side Panel
Model NumberBlack: Q300LV2-KGNN-S00, White: Q300LV2-WGNN-S00
Exterior ColorBlack, White
Materials – ExteriorSteel, Plastic
Materials – Left Side PanelTempered Glass
Dimensions (L x W x H)387 x 230 x 383mm (incl. Protrusions), 370 x 210 x 370mm (excl. Protrusions)
Volume29L (excl. Protrusions)
Motherboard SupportMini-ITX, Micro-ATX
Expansion Slots4
5.25″ Drive Bays0
3.5″ Drive Bays1
2.5″ Drive Bays2
I/O Panel – USB Ports2x USB 3.2 Gen 1 Type A, 1x USB 3.2 Gen 2 x 2 Type C
I/O Panel – Audio In / Out1x Audio Jack
Pre-installed Fans – TopN/A
Pre-installed Fans – FrontN/A
Pre-installed Fans – RearBlack: 1x 120mm, White: 1x 120mm (none LED, white)
Fan Support – Top2x 120mm
Fan Support – Front2x 120/140mm
Fan Support – Rear1x 120mm
Fan Support – Bottom1x 120mm
Radiator Support – Front120 / 240mm
Radiator Support – Rear120mm
Clearance – CPU Cooler159mm
Clearance – PSU160mm
Clearance – GFX360mm
Cable Routing – Behind Motherboard Tray28mm
Dust FiltersFront, Top, Bottom
Power Supply SupportBottom Mount, ATX
Warranty2 years
SizeMini Tower
SeriesQUBE Series
