TECHNICAL DETAILS:
Layout Keystone Entry: Double-row
Area of application: 483 mm (19″) cabinet
Norms: ISO/IEC 11801 3rd Ed., EN 50173-1, EIA/TIA 568-C
General properties:
Suitable for 483 mm (19″) cabinet mounting
Suitable for unshielded Digitus® Keystone Modules and Couplers
Technical properties:
Housing material: 1.5 mm SPCC cold rolled stell sheet, powder-coated
Material standard: EN 10 130(1991), BS 1449, NFA 36/401, DIN 1623, UNI 5866, UNE 36-086, SIS, JIS G 3141, ASTM, SAE, NFA 36/401
Physical properties:
Operation temperature: -20° C to +70 °C (ISO/IEC 11801, EN 50173-1, ANSI/TIA/EIA 568 C)
Colour: Black RAL9005
Color: black, RAL 9005
Ports: 16
Units: 1
