M32UP Gaming Monitor
Key Features Specification Support Gallery Buy
Panel Size (diagonal)
31.5” SS IPS
Display Viewing Area (HxV)
697.3056 x 392.2344 mm
Panel Backlight/ Type
Edge type
Display Surface(non-glare/ glare)
Non-glare
Color Saturation
90% DCI-P3/ 123% sRGB
True Resolution
3840 x 2160 (UHD)
Pixel Pitch
0.181(H) x 0.181(V) mm
Brightness
350 cd/m2(TYP)
Contrast Ratio
1000:1
Viewing Angle
178°(H)/178°(V)
Display Colors
16.7M
Response Time
1ms MPRT
Refresh Rate
160Hz
HDR
VESA Display HDR400
Flicker-free
Yes
Connectivity
2 x HDMI 2.1
1 x Displayport 1.4 (DSC)
1 x USB Type-C (Alternate Mode; Upstream port; Power Delivery up to 18W)
3 x USB 3.2 Downstream ports
1 x USB 3.2 Upstream port
1 x Earphone Jack
Speaker
3W x2
Unique Features
OSD Sidekick *
Aim Stabilizer Sync
Black Equalizer 2.0
Dashboard
Crosshair
Timer
Counter
Refresh Rate
Eagle Eye
Night Vision
PiP/PbP
Auto-Update
KVM
6 axis Color Control
Smart OD
Apply Picture Mode
HDMI-CEC
Power Type
Power Board Build-in
Power Consumption
41W **
Power Saving Mode
<0.5W
Power Off Mode
<0.3W
Voltage
AC 100V~240V /50~60Hz
Tilt(angle)
-5°~+20°
Swivel(angle)
-30°~+30°
Pivot(angle/direction)
N/A
Height Adjustment (mm)
130mm
VESA Wall Mounting(mm)
100*100 mm
Kensington lock
Yes
Phys. Dimension with Stand(WxHxD)
715.3*585.3*244.3 mm
Phys. Dimension w/o stand (WxHxD)
715.8*423.8*68.2 mm
Box Dimension (WxHxD)
990*536*192 mm
Net Weight with stand (Esti.)
10.35 kg
Net Weight without stand (Esti.)
7.25 kg
Gross Weight (Esti.)
13.464 kg
Accessories
Power cable/HDMI 2.1 cable/DP cable/USB cable/QSG/Warranty card
Note
*To enable OSD Sidekick, it requires connection between PC and monitor with USB (A-Male to B-Male) cable.
**The test condition follows CEC standards.
