Hardware Specifications
WiFi standard
–
10/100/1000 Mbps RJ-45 ports
3 x LAN/DMZ, 1 x WAN, 1 x OPT
USB 3.0 ports
1
Console port
RJ45
Rack-mountable
–
Fanless
Yes
System Capacity & Performance*1
SPI firewall throughput (Mbps)*2
900
VPN throughput (Mbps)
270
VPN IMIX Throughput (Mbps)*3
100
IPS throughput (Mbps)*4
540
Anti-Malware throughput (Mbps)*4
360
UTM throughput (Anti-malware & IPS, Mbps)*4
360
Max. TCP concurrent sessions*5
300,000
Recommended gateway-to-gateway IPsec VPN tunnels
20
Max. concurrent IPsec VPN tunnels*6
50
VLAN interface
8
Wireless Specifications
Standard compliance
–
Wireless frequency
–
Radio
–
SSID number
–
No. of antenna
–
Antenna gain
–
Data rate
–
Key Features
Security Service
Sandboxing*7
Yes
Reputation Filter*7
Yes
IPS*7
Yes
Application Patrol*7
Yes
Email Security*7
Yes
Web filtering*7
Yes
SecuReporter*7
Yes
Collaborative Detection & Response*7
Yes
SSL (HTTPS) Inspection
Yes
Geo Enforcer
Yes
2-Factor Authentication
Yes
Device Insight
Yes
Security Profile Sync*7
Yes
VPN Features
VPN
IKEv2, IPSec, L2TP/IPSec
Microsoft Azure
Yes
Amazon VPC
Yes
WLAN Management
Default Number of Managed AP
8
Recommend max. AP in 1 AP Group
10
Secure WiFi Service*7
Yes
Maximum No. of Tunnel-Mode AP
6
Maximum No. of Managed AP
24
Management & Connectivity
Nebula Cloud Mode
Yes
Nebula Cloud Monitoring Mode
Yes
Device HA Pro
–
Link Aggregation (LAG)
–
Hotspot Management*7
–
Ticket printer support*9/ Support Qty (max.)
–
Concurrent device logins (default/max.)*7*8
64
Burst login rate (users/30sec)
64
Power Requirements
Power input
12V DC, 2A max.
Max. power consumption (Watt Max.)
12.5
Heat dissipation (BTU/hr)
42.65
Physical Specifications
Item
Dimensions (WxDxH)(mm/in.): 216 x 147.3 x 33/8.50 x 5.80 x 1.30
Weight (kg/lb.): 0.85/1.87
Packing
Dimensions (WxDxH)(mm/in.): 284 x 190 x 100/11.18 x 7.48 x 3.94
Weight (kg/lb.): 1.40/3.09
Included accessories
Power adapter
RJ-45 – RS-232 cable for console connection
Environmental Specifications
Operating
Temperature: 0°C to 40°C / 32°F to 104°F
Humidity: 10% to 90% (non-condensing)
Storage
Temperature: -40°C to 70°C/-40°F to 158°F
Humidity: 10% to 90%(non-condensing)
MTBF (hr)
989,810 (at 25?) and 576,237 (at 40?)
Acoustic noise
–
Certifications
EMC
FCC Part 15 (Class B)
CE EMC (Class B)
BSMI
Safety
LVD (EN60950-1)
BSMI
